DC fast charging
40kW Wall-Mounted DC Fast Charger
Use this configuration when a wall-mounted DC charger must deliver 40 kW per port from a 400 or 480 VAC supply. Match the vehicle interface, current ceiling and single or parallel charging arrangement before quotation.
Match charging power to the vehicles and the site
Start with vehicle dwell time and available electricity, then confirm connectors, simultaneous charging and operating software.
- 01 Vehicle duty and parking time
- 02 Available site input power
- 03 Connector, payment and software scope
Application fit
Shortlist this model for a wall-mounted DC charging point where a 40 kW port and compact installation format fit the site plan.
Compatibility check
Match the three-phase supply, DC voltage window, selected connector current and single or parallel operating arrangement.
Matched configuration
We match the connector, cable assembly, current rating, parallel-charge option, mounting kit and supplied revision to the destination, application and quantity you send.
Send the destination, application, electrical supply and quantity. We will return a matched model, connector, accessories and delivery scope.
See the charger specifications that shape site fit
Compare output, input, connector, protection, networking and installation requirements as one system.
- Installation format
- Wall-mounted cabinet
- Rated power
- 40 kW per port
- AC input
- 400 / 480 VAC, 3P+N+PE; 50 / 60 Hz
- DC output voltage
- 200–1000 VDC
- CCS output current
- CCS1: 125 A; CCS2: 100 A
- CHAdeMO / GB/T output current
- CHAdeMO: 100 A; GB/T: 125 A
- Connector options
- CCS1, CCS2, CHAdeMO or GB/T
- Charge configuration
- Single connector; parallel charging optional
