CCS1 to CCS2 DC/AC Charging Adapter
Shortlist CCS1 to CCS2 DC/AC Charging Adapter for a CCS1 to CCS2 interface conversion that requires combined DC and AC charging. Check its 250A DC / 63A AC current rating and 1000VDC / 250VAC max voltage rating against the charging equipment and vehicle before ordering.
Confirm the full connection path before choosing an adapter
An adapter is selected by direction, charging mode and the exact equipment at both ends—not by connector shape alone.
- 01 Source and destination interfaces
- 02 AC, DC or discharge direction
- 03 Vehicle and charger communication
Application fit
Use this adapter when the required connector conversion is CCS1 to CCS2 and the charging path is combined DC and AC charging.
Compatibility check
Verify the CCS1 to CCS2 physical interfaces, 250A DC / 63A AC current limit, 1000VDC / 250VAC max voltage limit, charging communication, locking or interlock behavior and vehicle acceptance.
Matched configuration
We match order P/N EV.01.014, adapter orientation, hardware revision, electrical rating, interface details and the supplied protective and documentation scope to the destination, application and quantity you send.
Send the destination, application, electrical supply and quantity. We will return a matched model, connector, accessories and delivery scope.
Compare the ratings that control adapter compatibility
Use the interface direction, current, voltage and operating conditions to build a safe shortlist.
- Order P/N
- EV.01.014
- Adapter direction
- CCS1 to CCS2
- Rated current
- 250A DC / 63A AC
- Rated voltage
- 1000VDC / 250VAC max
- Protection rating, mated
- IP54
- Shell material
- Thermoplastic material
- Conductor material
- Copper alloy, silver-plated surface
Compare adjacent directions and interface options
Match this product to your project inputs
Send the destination, application, electrical requirements and quantity to receive a complete product proposal.
